20A DRL-24V480W1AA LYTE POWER SUPPLY 24VDC 480W 1PH

Features:

  • Universal AC input voltage range
  • Efficiency – up to 90.0% @ 230 VAC
  • Built-in constant current circuit for reactive loads
  • Conforms to harmonic current IEC/EN 61000-3-2, Class A

Description

Power supplies

Delta – worlds leading power supply manufacturer offers state-of-the-art designs made to withstand harsh industrial environments in accordance with ATEX requirements. The rugged ultra-compact case is both shock and vibration resistant according to IEC 60068-2.

General features:

  • Product features: RoHS compliant
  • Full corrosion resistant aluminium chassis
  • Provides – overload, overvoltage and thermal protection
  • Conformal coating on PCBAs to protect against chemical and dust pollutants
  • Certification: UL508, EN 60950, cULus 60950, EN 50178, EN 60204, GS, CCS Aus
  • Wide input voltage range 85 to 264 VAC (1 phase) – 320 to 600 VAC (3 phase)
  • Power boost (enables reserve power for reliable start up of loads with high inrush currents)

LYTE series

LYTE DIN rail economically priced, compact Power Supplies for general applications.

Features:

  • Universal AC input voltage range
  • Efficiency – up to 90.0% @ 230 VAC
  • Built-in constant current circuit for reactive loads
  • Conforms to harmonic current IEC/EN 61000-3-2, Class A
SERIES LYTE series
DESCRIPTION Power supply
INPUT VOLTAGE 85 – 264 VAC
OUTPUT VOLTAGE 24 VDC (adjustable)
RATED LOAD (W) 480
RATED LOAD (A) 20
HOUSING Aluminium
MOUNTING DIN rail
OPERATING TEMPERATURE -20 to + 70 °C
DIMENSIONS (MM) (H) 124 x (W) 86 x (D) 129
