Description
Output Voltage
24V
Output Power
480W
Output Current
20A
Input Voltage Range
3 x 320-575Vac (3-Phase) or 2 x 380-575Vac (2-Phase)
Dimensions (H x W x D)
124 x 65 x 127.1 mm
4.88” x 2.56” x 5.00”
Unit Weight
1.18kg (2.60 lb)
Highlights & Features
- Built-in constant current circuit for charging application
- Full power from -25°C to +60°C @ 5,000m (16,400 ft.)
- Power Boost of 150% up to 7 seconds
- Advanced Power Boost (APB) – protect system and ensure continuing operation when large inrush current detected due to faulty load on a multiple load connection
- DNV GL and ABS approvals for maritime applications
- Built-in DC OK Contact and LED indicator for DC OK/ Overload
- Conformal coating on PCBAs to protect against common dust and chemical pollutants
Tags
3 phase
