Description
| pplication | field installation |
|---|
Electrical data
| Operating voltage [V] | 26.5…31.6 DC |
|---|---|
| Max. current consumption from AS-i [mA] | 140 |
| Reverse polarity protection | yes |
| Additional voltage supply [V] | 24…30 DC; (AUX) |
| Additional voltage supply | optional |
| Max. current consumption from additional supply [mA] | 550; (AUX) |
Inputs / outputs
| Number of inputs and outputs | Number of analogue outputs: 2 |
|---|
Inputs
| Precision analogue input [%] | 0,5 |
|---|
Outputs
| Number of analogue outputs | 2; (connection of 2-wire or 4-wire actuators) |
|---|---|
| Analogue current output [mA] | 0…20 |
| Max. load [Ω] | 600 |
| Overload protection | yes |
| Resolution of analogue output | 16 (1 bit = 1 µA) |
| Actuator supply outputs | AS-i / AUX |
Operating conditions
| Ambient temperature [°C] | 0…70 |
|---|---|
| Storage temperature [°C] | -25…85 |
| Max. relative air humidity [%] | 90; (non condensing) |
| Max. height above sea level [m] | 2000 |
| Protection | IP 65 |
Tests / approvals
| EMC |
|
||
|---|---|---|---|
| MTTF [years] | 145 |
AS-i classification
