Description
Output Voltage
48V
Output Power
60W
Output Current
1.25A
Input Voltage Range
85-264Vac
Dimensions (H x W x D)
121 x 32 x 125 mm
4.76” x 1.26” x 4.92”
Unit Weight
0.38 kg (0.84 lb)
Highlights & Features
- Universal AC input voltage range
- Power will not de-rate for the entire input voltage range
- Power Boost of 150% for 5 seconds
- Full corrosion resistant aluminium casing
- Conforms to harmonic current IEC/EN 61000-3-2, Class A
- Extreme low temperature cold start at -40°C
- Conformal coating on PCBAs to protect against common dust and chemical pollutants
- Hazardous Locations approval for ATEX and Class I, Div 2 (DRP048V060W1BA)
- Certified according to IEC/EN/UL 62368-1
Tags
ATEX, Class I Div 2, Conformal Coating, DRP048V060W1BN
